TR330

High Traction Side Shifting Trim Mower
Jake's Take
Quality Cut and Control in the Palm of Your Hand

Comfort, cut quality, maneuverability, and power come together to make a mower that can safely reach every blade of grass on your golf course. The TR330 provides Jake’s Signature Cut Trusted by Generations and side-shifting reels can trim around bunkers, ponds, lakes, and other hazards with ease.

Technical Specs

Choose a Section
    Key Attributes
    Reels and Blades
    Traction, Brakes and Speed
    Weight and Dimensions
Key Attributes
Reels and Blades
Traction, Brakes and Speed
Weight and Dimensions
Mower Cutting Width72" (1.83 m) or 84" (2.13 m) featuring ADAPTISHIFT™ with up to 12" (30.5 cm) of offset
Mower Height of Cut0.37 - 2.75" (9.5 - 69.8 mm)
Blades per Reel5, 7 or 11
Fuel/Battery Capacity (+Run Time)7.6 gal. (28.7 L)
Mower EngineKubota 24.8 HP (18.6 kW) Diesel
Cutting Capacity 4.5 - 5.3 acres (1.83 - 2.13 hectare) / hr
Mower Warranty2 Years
Number and Size3 x 26" (66.0 cm) or 30" (76.2 cm) reels; 7" (178 mm) diameter
Blade MaterialHardened, high manganese carbon steel
Cutting Unit LiftArmrest mounted joystick
Cutting Frequency-
Traction DriveParallel-series "on-demand" 3WD
Reel DriveFixed displacement hydraulic
Hydraulic System8.7 gal. (33 L) capacity, full flow filtration (10 micron filter); GreensCare biodegradable oil
Service BrakesDynamic braking through hydrostatic drive
Parking BrakesService-free electronic wet disc
SteeringHydraulic power steering with tilt wheel
Mowing Speed6.2 mph (10 kph)
Transport Speed8.7 mph (14 kph)
Tires-
Weight1664 - 2299 lbs. (755 - 1043 kg)
Length (less catchers)97" (2.46 m)
Overall Height including ROPS80" (2.04 m)
Wheel Base43.5" (1.36 m)
Transport Width83" (2.11 m)
Working Width83" (2.11 m)
Fluid Capacities-
Specifications, while correct at time of publishing, may change without notice.
