Greens King® IV Plus
Diesel/Gas Greens Reel Mower
Jake's Take
Our Reigning Golf Green Cutting Machine
Light, trusted, proven around the world, the Greens King is a reel mower for golf greens. Simple to operate, and easy to maintain, delivering Jake's Signature Cut, Trusted by Generations. Used where quality, reliability and simplicity are paramount.
Key Features
Sheet
![Greens King Iv Plus with Power Steering](https://www.jacobsen.com/sites/default/files/styles/compress/public/2021-01/Greens%20King%20Iv%20Plus%20-%20Feature%201.jpg?itok=F-Hd_xDg)
Power Steering
![Greens King IV Plus with Walk-through Operator Station](https://www.jacobsen.com/sites/default/files/styles/compress/public/2021-01/Greens%20King%20IV%20Plus%20-%20Feature%202.jpg?itok=FiBgFr0c)
Walk-through Operator Station
![Jacobsen Greens King IV Plus with Steerable Cutting heads Move Independently](https://www.jacobsen.com/sites/default/files/styles/compress/public/2021-01/Greens%20King%20IV%20Plus%20-%20Feature%203.jpg?itok=n6bfb-yt)
Free-floating, Steerable Cutting heads Move Independently
![Jacobsen On-Board Backlapping](https://www.jacobsen.com/sites/default/files/styles/compress/public/2021-01/Greens%20King%20IV%20Plus%20-%20Feature%204.jpg?itok=4Ru6wLi2)
On-Board Backlapping
Technical Specs
Choose a Section
Key Attributes
Reels and Blades
Traction, Brakes and Speed
Weight and Dimensions
Key Attributes
Reels and Blades
Traction, Brakes and Speed
Weight and Dimensions
Mower Cutting Width | 62" (1.6 m) |
Mower Height of Cut | 0.062 - 0.438" (1.6 - 11.1 mm) |
Blades per Reel | 7, 9 or 11 |
Fuel/Battery Capacity (+Run Time) | 8 gal. (31 L) |
Mower Engine | Gas 18 HP (13.4 kW); Diesel 17.7 HP (13.2 kW) |
Cutting Capacity | - |
Mower Warranty | 2 Years |
Number and Size | 3 x 22" (56 cm) reels; 5" (127 mm) diameter |
Blade Material | Hardened, high manganese carbon steel |
Cutting Unit Lift | Hydraulic lift |
Cutting Frequency | 5 Blade: 0.035 in/mph (0.889 mm/kph), 11 Blade: 0.053 in/mph (0.836 mm/kph) |
Traction Drive | Hydraulic motor on each drive wheel |
Reel Drive | Gear-type hydraulic motor; backlap control valve standard |
Hydraulic System | Hydraulic double action cylinders; 5 gal. (18.9 L) capacity; 20-micron, full flow filtration; biodegradable fluid |
Service Brakes | Dynamic braking through the hydraulic system |
Parking Brakes | Internal expanding, hand operated |
Steering | Power Steering |
Mowing Speed | 3.7 mph (6 kph) |
Transport Speed | 6.6 mph (10.6 kph) |
Tires | 18 x 9.5-8, 2-ply, pneumatic, tubeless |
Weight | Gas: 1073 lbs. (486.7 kg), Diesel: 1174 lbs. (532.5 kg) |
Length (less catchers) | 87.5" (2.22 m) |
Overall Height including ROPS | 78" (1.98 m) |
Wheel Base | 51.5" (1.34 m) |
Transport Width | 50.5" (1.27 m) |
Working Width | 70" (1.78 m) |
Fluid Capacities | Coolant Capacity: 0.75 gl. (2.85 L) Pressurized, sealed cooling system |
Specifications, while correct at time of publishing, may change without notice.
