Eclipse 360 ELiTE
Lithium Ride-on Reel Mower
Jake's Take
Our Lithium Green Mower
The Eclipse 360 ELiTE cuts more than grass. Battery use, noise, and maintenance downtime are all reduced by a mower with precision lithium technology powered by Samsung SDI that gives you a perfect cut every time on football fields, elite-level soccer fields, and other fine sports turf.
Key Features
Sheet
![Eclipse 360 ELiTE - Feature 1- Greatest Cutting and Run Range](https://www.jacobsen.com/sites/default/files/styles/compress/public/2021-01/Eclipse%20360%20ELiTE%20-%20Feature%201%20%281%29.jpg?itok=Bx5vALvT)
Jake's Greatest Cutting and Run Range
![Eclipse 360 ELiTE - Feature 2- ELiTE Lithium Battery](https://www.jacobsen.com/sites/default/files/styles/compress/public/2021-01/Eclipse%20360%20ELiTE%20-%20Feature%202%20%283%29.jpg?itok=rdraU3VI)
ELiTE Lithium Battery
![Eclipse 360 ELiTE - Feature 3- Built on Experience](https://www.jacobsen.com/sites/default/files/styles/compress/public/2021-01/Eclipse%20360%20ELiTE%20-%20Feature%203%20%282%29.jpg?itok=XKKCuYXM)
No Hydraulic Oil
![Eclipse 360 ELiTE - Feature 4 - Swing Out Center](https://www.jacobsen.com/sites/default/files/styles/compress/public/2021-01/Eclipse%20360%20ELiTE%20-%20Feature%204%20%281%29.jpg?itok=ig6lJkJu)
Unique Swing out Center Cutting Unit for Ease of Service
Technical Specs
Choose a Section
Key Attributes
Reels and Blades
Traction, Brakes and Speed
Weight and Dimensions
Key Attributes
Reels and Blades
Traction, Brakes and Speed
Weight and Dimensions
Mower Cutting Width | 62" (1.6 m) |
Mower Height of Cut | 0.062 - 0.438" (1.6 - 11.1 mm) |
Blades per Reel | 7, 9, 11 or 15 |
Fuel/Battery Capacity (+Run Time) | Lithium Battery - 250 Ah lithium pack, 12.2 kW/hrs. |
Mower Engine | Lithium Battery with onboard charger |
Cutting Capacity | Cut 143K sq. ft (12,449 sq. m) of greens + 6 miles (9.65 km) of transport with groomers and brushes installed |
Mower Warranty | 2 Year Machine & 5 Year Battery |
Number and Size | 3 x 22" (55.88 cm) reels; 5" (127 mm) diameter |
Blade Material | Hardened, high manganese carbon steel |
Cutting Unit Lift | New Long Life linear actuator |
Cutting Frequency | 0.036 - 0.250" (0.91 - 6.35 mm) with 15 blade reel, electronically adjustable |
Traction Drive | Front / 2WD - AC; 4.4 HP (3.3 kW) continuous (Optional 3WD - PM; 3.2 HP (2.4 kW)) |
Reel Drive | One brushless DC motor per reel 1.3 HP (0.97 kW) continuous |
Hydraulic System | No Hydraulic Oil |
Service Brakes | Dynamic regenerative braking system |
Parking Brakes | Automatic electro-magnetic multi-plate |
Steering | Variable ratio Drive-by-wire steering with feedback control |
Mowing Speed | 0 - 5.0 mph (0 - 8.9 kph); electronically adjustable max speed |
Transport Speed | 0 - 9.0 mph (0 - 14.5 kph) electronically adjustable max speed |
Tires | 18 x 10.5 x 8 4-ply |
Weight | 1,598 lbs. (725 kg) with groomers, rear roller brushes, grass boxes and 15 blade reels, charger and aluminum front rollers |
Length (less catchers) | 101" (2.56 m) (with Catchers) |
Overall Height including ROPS | 79.3" (2.01 m) |
Wheel Base | 52" (1.32 m) |
Transport Width | 67.7" (1.72 m) |
Working Width | 67.7" (1.72 m) |
Fluid Capacities | - |
