Jacobsen HR800 trim mower

HR700

Powerful Large Area Rotary Mower

Jake's Take

Widest Width of Cut in Class

Cut roughs, surrounds, and large areas effortlessly in all conditions with the powerful HR700. A narrow transport width makes every area of the course accessible, with zero maintenance decks and unrivalled operator comfort keeping you on cut and on course until the work is done.

Key Features

Jacobsen HR700 Large Area Rotary Mower

Low Maintenance, Direct Drive Hydraulic Decks

Jacobsen HR700 wide area rotary mower

Widest Width of Cut and The Narrowest Transport Width in Class

HR700 Jacobsen

Tilt Sensor Technology (TST) Warns of Unsafe Working Angle

Jacobsen HR700 mower with Low Weight for Efficiency and Fuel Economy

High Strength, Low Weight Design for Efficiency and Fuel Economy

Technical Specs

Choose a Section

Key Attributes

Decks and Cutting Units

Traction, Brakes and Speed

Weight and Dimensions

Key Attributes

Decks and Cutting Units

Traction, Brakes and Speed

Weight and Dimensions

Mower Cutting Width	168" (4.27 m)
Mower Height of Cut	1 - 4.5" (25-114 mm) in 0.25" (6.4 mm) increments
Mower Engine	Kubota 65.2 HP (48.6 kW) Turbo Diesel
Cutting Capacity	17 acres/hr at 10 mph (6.9 ha/hr. at 16 km/h)
Transport Speed	15.5 mph (25 km/h)
Fuel/Battery Capacity (+Run Time)	20.4 gal. (77.1 L)
Mower Warranty	2 Years

Number and Size	1 x 60" (1.52 m) front deck; 2 x 60" (1.52 m) wing units
Blade Material	MARBAIN® boron alloy steel
Deck Lift/Lower	Individual via fingertip operated joysticks
Weight Transfer	On demand electrically operated hydraulic weight transfer system
Deck Construction	11 gauge (3 mm) Strenx, high strength steel shell

Traction Drive	Hydrostatic closed loop parallel-cross-series SureTrac™ system
Deck Drive	Nine individual hydraulic motors with self lubricating integral bearings
Hydraulic System	13.3 gal. (50.2 L) reservoir with 10 micron remote charge filters and suction screening at tank. Oil cooler in side by side radiator.
Service Brakes	Dynamic through hydrostatic traction system
Parking Brakes	Automatic wet parking brakes integrated into wheel motors
Steering	Power Steering
Mowing Speed	10 mph (16.4 km/h)
Reverse Speed	4 mph (6.4 km/h)
Tyres	Front Tyres: 26 x 12-12 tubeless 8 ply. Rear Tyres :20 x 10-8 tubeless 6 ply

Weight	4023 lbs. (1825 kg), 4479 lbs. (2032 kg) with cab
Length	143" (3.62 m) front deck down
Height (Rops Up)	83" (2.1 m)
Wheel Base	64" (1.65 m)
Transport Width	65" (1.67 m)
Working Width	176" (4.48m)
Fluid Capacities	Coolant System and Capacity: Side-by-side radiator/hydraulic oil cooler; pressurized; 2 gl. (7.6 L) capacity, 8.5 fins per inch

Specifications, while correct at time of publishing, may change without notice. Available in ultra low sulfur diesel countries only. Cab optional.
