Eclipse 2 Hybrid

Electric Hybrid Walk-Behind Reel Mower
Jake's Take
The Master in Cut Quality

Whether you're cutting baseball in-fields or lawn tennis courts the Eclipse 2 hybrid reel mower guarantees Jake's Signature Cut Trusted by Generations. Programmable settings give you control to ensure consistency with every use to deliver fine sports turf surfaces precisely as you want them.

Technical Specs

Choose a Section
    Key Attributes
    Reels and Blades
    Traction, Brakes and Speed
    Weight and Dimensions
Key Attributes
Reels and Blades
Traction, Brakes and Speed
Weight and Dimensions
Mower Cutting Width18" (0.46 m), 22" (0.55 m), or 26" (0.66 m) Cutting Width
Mower Height of Cut18" and 22" units: 0.062 - 0.438" (1.6 - 11.1 mm) (bench setting)
Blades per Reel7, 11 or 15
Mower EngineHonda® GX-120 Gas Engine driving a 48v brushless generator | Hybrid Electric drivetrain powered by 4hp Gas Engine
Fuel/Battery Capacity0.66 gal. (2.5 L)
PowerHybrid Electric drivetrain powered by Honda 4 HP Gas Engine
Sound Level88 dBA
Mower Warranty2 Years
Blade MaterialHardened, high manganese carbon steel
Reel SpeedElectronically controlled, 2200 RPM maximum
Frequency of ClipProgrammable electronically controlled Frequency of Clip based on actual machine speed
Mower Drive SystemHonda® GX-120 gas engine driving a 48v brushless generator
Traction Drive7.75" (19.68 cm) diameter machine smoothed aluminum drum driven via a brushless DC motor and synchronous belt
Operator Presence ControlStandard InCommand™ operator controls (Traction and Reel) with integrated Operator Presence Control
DifferentialFull automotive type, housed in traction drum
Traction Drum7.75" (19.68 cm) diameter smooth machined aluminum
BrakesLever actuated hub brake with parking lock
Transport Wheels2 x Pneumatic 11" x 4" (27.94 x 10 cm)
Mowing SpeedElectronically controlled and programable 0 - 3.8 mph (6.12 kph) max
Weight18": 213 lbs. (97 kg), 22": 229 lbs. (104 kg), 18" floating head: 248 lbs. (113 kg), 22" floating head: 252 lbs. (114 kg) (all weights are with Catcher, grooved steel roller and Kickstand)
Engine horsepower may vary due to conditions of specific use. Product available in selected countries. Not available in China.
