NEW
AR730
LARGE, ARTICULATED CONTOUR ROTARY MOWER
Jake's Take
Our widest and most efficient fine cut rotary mower.
The AR730 provides unmatched clip dispersal and after-cut appearance, whether you’re cutting with five or seven decks, thanks to innovative TrueDeck construction. Designed to easily cover the most complex and demanding terrain, the SureTrac II™ all-wheel drive traction system climbs undulations with ease and provides exceptional side slope performance.
Key Features
5 OR 7 TRUEDECK™ HEAVY-DUTY CONTOURING
SUPERIOR AFTER-CUT APPEARANCE
QUICK AND EASY DECK ADJUSTMENT
POWERFUL, TRUSTWORTHY ENGINE
Technical Specs
Choose a Section
Key Attributes
Decks and Cutting Units
Traction, Brakes and Speed
Weight and Dimensions
Key Attributes
Decks and Cutting Units
Traction, Brakes and Speed
Weight and Dimensions
| Mower Cutting Width | 124" (3.15 m) |
| Mower Height of Cut | 0.75 - 4.5" (19 - 114 mm) in 0.25" (6 mm) increments |
| Mower Engine | Kubota 65.2 HP (48.6 kW) Diesel |
| Cutting Capacity | Up to 8.7 acres/hr at 7 mph (3.52 ha/hr at 11.27 kph) (no overlaps or stops) |
| Transport Speed | 11 mph (17.7 kph) |
| Fuel/Battery Capacity (+Run Time) | 17 gal. (64.2 L) |
| Mower Warranty | 2 Years |
| Number and Size | 7 x TRUEDECK™ 23" (58.4 cm) rotary cutting units. Equipped for rear-discharge chute and smooth rear roller. Mulching baffle, non-striping rear roller and rear roller scrapers available. |
| Blade Material | 7 x 22.4" (56.8 cm) heat treated alloy combo blades |
| Deck Lift/Lower | Hand operated, joystick controlled hydraulic lift system. Wing decks can be deactivated and lifted independently. |
| Weight Transfer | Adjustable hydraulic weight transfer – automatic electronic activation at operator controls with mow switch. Selectable through control console |
| Deck Construction | 10-gauge, heavy duty modular deck construction |
| Traction Drive | SureTrac II™ AWD, a unique parallel hydrostatic system, servo-controlled variable displacement hydro; four high-torque wheel motors; 2WD transport and reverse |
| Deck Drive | Fixed displacement, self-lubricating with 1" (2.54 cm) diameter shaft; double sealed bearings |
| Hydraulic System | 10 gal. (37.9 L) capacity; hydraulic tank oil level monitor and horn alarm; GreensCare biodegradable fluid; full-flow, 10-micron filter, 40 gpm. Side-by-side radiator/hydraulic oil cooler. |
| Service Brakes | Dynamic through traction system |
| Parking Brakes | No-Maintenance, Integrated Wet Parking Brake |
| Steering | Rear wheel, hydrostatic power steering with tilt adjustable steering wheel |
| Mowing Speed | 7 mph (11.3 kph) |
| Reverse Speed | 8.7 mph (14 kph) |
| Tires | - |
| Weight | 4235 lbs. (1921 kg) full fluids |
| Length | 137.5" (3.49 m) |
| Height (Rops Up) | 91.6" (232.6 cm) |
| Wheel Base | 63" (1.6 m) |
| Transport Width | 88.6" (2.25 m) |
| Working Width | 133" (3.38 m) |
| Fluid Capacities | - |
Engine horsepower may vary due to conditions of specific use. Product available in selected countries.
